Weight | 0,014 kg |
---|---|
Dimensions | 82 × 13 × 13 mm |
Milling Material | Aluminum, Brass, Copper, Gold, Non-Ferrous, Plastic, Stainless Steel, Titanium |
Coating Type (CT) | No Coating |
Special Series | No |
Cutting Diameter (CD) | 1.0mm |
Cutting Geometry | Ball-Nosed |
Flutes | 2 |
Shank Diameter (SD) | 4mm |
Flute Length (FL) | 1.6mm |
Reach Length (RL) | 20mm |
Overall Length (OL) | 50mm |
Neck Diameter (ND) | 0.95mm |
Remeasured to 1 Micron | No |
Sample Box | no |
NT.UNC.B2.10.4.200.50.X
1mm 2-Flute Ball Carbide End Mill for Non-Ferrous
No Coating, Shaft Diameter of 4mm.
HS Code: 82077010
In stock (can be backordered)
